    PU Camlock 200mm Thick Blast Freezer Room Panel

    Ask Lasest Price
    Brand Name : SINCOOL
    Model Number : CR
    Certification : CE,CB, SASO
    Price : Negotiable
    Payment Terms : L/C, D/P, T/T, Western Union
    Supply Ability : 100 Units per Month
    Delivery Time : 25 Days
    • Product Details
    • Company Profile

    PU Camlock 200mm Thick Blast Freezer Room Panel

    For blast freezer room, its room temperature is as low as -40 degrees celsius, or even lower. The 200mm thick PU panel is reuqired to build a blast freezer room.

    PU cold storage room panel is a kind of board used for enclosing structures, which has good heat insulation. It can reduce the heat transmission caused by difference in the internal and external temperature, and get to maximum efficiency of freezing and refrigeration systems. It is a new type of heat insulation material for lower construction cost. Panels are in multiple varieties and specifications to meet the need of various sites and projects.

    The standard panel thickness: 50mm, 75mm, 100mm, 120mm, 150mm, 175mm and 200mm

    The standard color steel thickness: 0.3mm, 0.326mm, 0.35mm, 0.376mm, 0.4mm, 0.426mm, 0.5mm, 0.6mm


    Product namePolyurethane(PU) Sandwich Board
    Thicknessupper layer0.3-0.8mm
    core material75mm, 100mm, 120mm,150mm,200mm
    bottom layer0.3-0.8mm
    Effective Widthstandard950mm, 970mm,1000mm,1150mm
    othercan be customized
    Lengthcan be customized,less than 12m
    Density40-42kg/m3
    Weightup to model
    Colorany(generally white,blue,red,grey,)
    Temp tolerance-120-90℃
    Fire resistance levelA2(incombustible)
    Surface profileflat,corrugated,big rib, small wave
    Compression bearing≥0.2Mpa
    Materialupper layerPPGI(prepainted galvanised steel)color steel sheet
    inner layerPU foam(injected,not glued)
    bottom layerPPGI(prepainted galvanised steel)color steel sheet
    PartsEccentric hook used for connection of panel
    Film covering for protecting the surface layer
    Heat transfer coefficient0.019 W/M*K
    Characteristicsheat insulation energy-saving100mm width can keep temp at 0℃(suit for fresh keeping)
    150mm width can keep temp at -18℃(suit for cold storage)
    200mm width can keep temp at -38℃(suit for freezing)
    Water resistance and sound proof
    Weather proofing
    Fire retardant level:B
    High strength and bending resistance
    Easy quick installation and dismantling,labour cost saving
    Light weight compared to traditional stone or plaster panel
    Safe and green,good appearance,without formaldehyde
    Lifespancan reach 15-20 years
    UsageCan be used for wall,roof,floor and partition of cold storage, mobile house, suburban housing, suburban housing,industrial plants, warehouses, supermarkets, hospitals, stadiums, activities room,clean workshop and reconstruction residence, villa, kindergarten, commercial building, remodeling of old structures, heat insulation fire places, airport, etc.
